Description
Fluidtrol Model SS basket strainers are manufactured from one of three different formulations of FRP depending upon the fluid characteristics. Generally speaking these solid FRP simplex basket strainers are used for extremely aggressive chemicals and higher temperatures. All designs feature joining with tapered adhesive butt & wrap or o-ring joints and are UV protected. Fire retardant resins are an option for all variations.
P Series
-
Bisphenol A vinyl ester resin (Derakane 411 or Hetron 922)
-
Integral corrosion resistant liner
-
50 to 150 PSI rated
-
Maximum temperature rating of 180F
-
For moderate to aggressive corrosion environments
H Series
-
Bisphenol A vinyl ester resin or epoxy Novolac vinyl ester resin (Derakane 470 or Hetron 970)
-
Custom designed corrosion barriers
-
50 to 150 PSI rated
-
Maximum temperature rating of 220F
-
Used for hot concentrated HCL, typical of mineral process industries
A Series
-
Resistance to chlorides and fluorides (Derakane 411/470 or Hetron 922/970)
-
Integral corrosion resistant liner
-
50 to 150 PSI rated
-
Maximum temperature rating of 180F
-
Used for FGD applications due to much better wear resistance than rubber lined carbon steel
